Prémium KISFESZÜLTSÉGŰ KONTAKTOR LT1-D 50A 12V 1NO+1NC

Technical characteristics:
– Operation class: АС-3
– Rated current: 6-95А
– Rated operating voltage of power contactors: up to 690V, 50/60Hz
– Surge voltage wear resistance: &amp,gt,8000V
– Rated operating voltage of the coil: 12/24/36/48/110/230/400
– Electrical wear resistance (number of cycles): &amp,ge,1000000
– Mechanical wear resistance (number of cycles):&amp,ge,10000000
– Number of cycles (switchings ON) per hour:
&amp,nbsp, &amp,nbsp,6-32А – 1200cycles
&amp,nbsp, &amp,nbsp,40-95А – 600cycles
– Pole leaking power: up to 13W
– Ambient temperature: -10&amp,deg,&amp,divide,60&amp,ordm,С
– Maximum altitude: up to 2000m

n

Mounting: on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of &amp,plusmn,5&amp,deg,

n

Standards: EN60947-1, EN60947-4-1
